Description
Brother's most advanced colour printing technology is guaranteed to make the right impression when it counts. Producing vibrant, professional colour documents and accurate digital files every time. With NFC (for mobile print & card authentication) as standard for secure printing and a large customisable touchscreen, it's ideal for busy offices requiring a user-friendly printer with enterprise level security.
- Print up to 40ppm (pages per minute)
- 2-sided print, up to 28 sides per minute
- 2-sided scan up to 100ipm (images per minute) colour and mono
- 520 Sheet paper input tray expandable to 2,600
- 100 sheets Automatic Document Feeder (ADF)
- Large 17.6cm touch screen
- Integrated NFC reader
- Cloud Secure Print
- Gigabit network as standard with optional 2.4/5GHz Wi-Fi module
- Expandable memory capacity (USB flash drive not included)
- Fully compatible with 3rd party print management and document management solutions including Kofax, YSoft and more
*Approx declared toner yield value in accordance with ISO/IEC 19798
Specifications
General
| Printer type | Colour |
|---|---|
| Function | Print, Copy and Scan, Fax |
| Display | Colour touchscreen |
| Display size | 17.6cm |
| Laser classification | Class 1 Laser Product |
| Max paper size | A4 |
| Memory | 2GB Internal |
Connectivity
| Connectivity | Wired Network |
|---|---|
| Local interface | Hi-Speed USB 2.0 & USB Host (Front | Rear) |
| NFC | Integrated NFC Reader Supported for printing and scanning. NFC standards include: (ISO14443 Type A) MIFARE Standard/Plus/ Ultralight/Ultralight C/DESfire my-d move, Tag-it (ISO15693 Type B) |
| Wired network interface | GigE (10Base-T/100Base-TX/1000Base-T) |
| Wireless network interface | Optional accessory |
Mobile connectivity
| Supported | AirPrint, Mopria, Brother Print Service Plugin, Brother Apps, Web Connect |
|---|
Copying
| 2-sided copy | Yes |
|---|---|
| Resolution | 600 x 600dpi |
| Speed | Up to 40ppm |
| Enlargement / reduction ratio | Reduce or Increase document sizes from 25% to 400% in 1% increments |
| N in 1 | Yes |
Dimensions & weights
| With carton | 580 x 663.7 x 734mm |
|---|---|
| With carton | 42.7 kg |
| Without carton | 503 x 541 x 586mm |
| Weight | 36.5 kg |
Faxing
| Fax modem | 33.6 kbps |
|---|---|
| Internet fax | Yes |
| PC Fax | Yes |
Environment
| Operating humidity | 20-80% |
|---|---|
| Operating temperature | 10-32 Celsius |
| Storage humidity | 10-90% |
| Storage temperature | 0-40 Celsius |
| Sound power | Printing 6.79BA, Ready 3.06BA, Quiet Mode 6.68BA, Deep Sleep 3.06BA |
| Sound pressure | Printing 56.5dbA, Ready 17.2dbA, Quiet Mode 53dbA |
Environmental
| Nordic Swan environmental accreditation | Yes |
|---|---|
| Power consumption (Watts) | Printing - 770W (430W in quiet mode), Copying 730W (420W in quiet mode), Ready 85W, Sleep 16.8W, Deep Sleep 1.1W, Power Off 0.04W |
| Typical electrical consumption | 0.687kWh/Week |
In the box
| Contents | Machine, Inbox Toners, Drum, Belt, Waste Toner Box, Power Supply Cord, Quick Set-Up Guide, Warranty Card (PC interface cable NOT included) |
|---|
Media specifications
| Types and sizes | Media Types including, Thin Paper, Plain Paper, Thick Paper, Thicker Paper, Recycled Paper, Bond Paper, Label, Envelopes, Glossy Paper. Media sizes up to Width: 76.2mm - 215.9mm Length: 127mm - 355.6mm |
|---|---|
| Weights | Standard (Tray 1) and Multi Purpose Tray 60 - 230gsm, Automatic Document Feeder (ADF) 45 - 120gsm, Optional (Trays 2-5) 64 - 105gsm |
Operating systems & software
| Software supplied - Mac | Brother iPrint&Scan, Utilities, Easy Setup |
|---|---|
| Software supplied - Windows | Brother iPrint&Scan, Utilities, Easy Setup, PaperPort SE 14, BRAdmin Professional, Mass Deployment Tool, Status Monitor |
Paper handling
| Paper input | Standard Tray1 - Up to 520 sheets, Multi Purpose Tray - Up to 100 sheets, 15 Envelopes, ADF (Automatic Document Feeder) - Up to 100 sheets |
|---|---|
| Paper output | 250 sheets face down, 1 sheet face up (straight path) |
Printing
| Resolution | 2,400 dpi class (2400 x 600), 600 x 600 dpi quality |
|---|---|
| A4 2-sided colour print speed | 28 pages per minute |
| A4 standard colour print speed | 40 pages per minute |
| Automatic 2 sided print | Yes |
| Emulations | PCL5e, PCL5c, PCL6（PCL XL Class3.0）, BR-Script3, PDF Version 1.7, XPS Version 1.0 |
| First print out time | Less than 10 seconds |
| Recommended monthly volume | 12,000 pages |
Scanning
| 2-Sided scan | Yes |
|---|---|
| Resolution | Up to 600 x 600 dpi from ADF(Optical), up to 600 x 600 dpi from Glass(Optical), up to 19,200 x 19,200 dpi from (Interpolated) |
| Scan to | Scan to USB, USB flash memory, E-mail, Image, File, Scan to network folder (Windows Only), FTP, SFTP, Email Server, SharePoint On-premise |
| Speed | 100 ipm colour & mono |
| Scanner type | Dual CIS |
Security features
| 802.1x | Yes |
|---|---|
| Active Directory LDAP Authentication | Yes |
| Automatic Intrusion Detection | Yes |
| Digitally-signed Firmware | Yes |
| IP filter | Yes |
| NFC | Yes |
| Port based Network Access Control | Yes |
| Restrict network protocols | Yes |
| Secure function lock v3 | Yes |
| Secure Key Management | Yes |
| Secure print | Yes |
| Secure printing with SSL | Yes |
| Setting lock | Yes |
| Store Print Log | Yes |
| SysLog | Yes |
Solutions
| Brother Solutions Interface | Yes |
|---|---|
| Cloud Secure Print | Yes |
Supplies and accessories
| Accessories | LT-330CL, LT-340CL, TT-4000, TC-4100, NC-9000w, FH-3000, CH-1000 |
|---|---|
| Supplies | TN821XL, TN821XXL, DR821CL, BU800CL, WT-800CL |
Overview
Solutions enabled out the box
The MFC-L9630CDN comes with Cloud Secure Print straight out the box, so you can securely print your documents directly from the cloud. You also have the option to further enhance your device with third party solutions, meaning that you can have a fully integrated print, capture and output management solution all from one provider.
Enterprise level security
Built-in support for the latest industry-standard security protocols to securely protect your data. You can further protect your device by setting up user authentication, whereby access to certain settings and functions is only given to authorised users.
Quality and performance
Impressive colour and high-quality outputs makes the MFC-L9630CDN the device of choice for many businesses. The robust design and long life components provides complete peace of mind that you can keep on printing and scanning without interruption.
Flexibility for your business
Designed to fit into your office space and meet your specific print and scan requirements, the MFC-L9630CDN is available as a low-profile desktop printer and easily transformed to a highly efficient floor-standing model by simply adding optional paper trays and storage cabinet.
Contract printing that looks after itself
Get the most out of your MFC-L9630CDN with managed print services. Your business can easily manage and control print costs and have the high-yield toners you need, when they need them.
