Description
Fujitsu Interactive Panel is the essential hub for modern meeting spaces as well as digitize classrooms. It offers unparalleled visual performance and fosters collaboration to elevate meeting and teaching efficiency.
富士通互動觸控智能顯示屏是現代會議和教室的重要工具。 它提供了無與倫比的視覺效果，，取代了傳統的書寫白板，促進商業溝通，以及提高會議和教學效率。
歡迎聯繫我們獲取企業用戶報價。 安排示範或提供現場安裝方案。
Contact us for a quotation for enterprise user price. And demonstration or onsite installation recommendation are welcome.
Interactive 55" display with 4K resolution offers big viewing experience
High accuracy touch experience with intuitive 20 points of touch
Resistant to optical interference (use as usual under direct sunlight)
Rapid response, fluent in writing & demonstration
Durable whiteboard surface. AG tempered glass Mohs level 7
Multi OS + multi modules. Seamless switching between OS
Built-in Android. Concealed WIFI module, compatible with WIFI 6 networks
Warranty : 3 Year Onsite (Hong Kong)
Technical Details
| Product Name | Interactive Panel IW552 Plus |
|---|---|
| Picture Performance | |
| Panel backlit | DLED |
| Screen surface treatment | AG tempered glass Mohs level 7 |
| Contrast – typical | 1,200:1 |
| Viewing angle (h/v) - typical | 178° |
| Color performance | 1.07 billion colors |
| Brightness – typical | 350 cd/m² (Typ) |
| Flicker-free technology | Supports |
| Low blue light | Supports |
| Anti-glare filter | Supports |
| Built-in ambient light sensor | Yes |
| Size and Resolution | |
| Aspect ratio | 16:09 |
| Resolution (native) | 3,840 (H) x 2,160 (V) |
| Picture Size (H x V) | 1,209.6 x 680.4 mm |
| Pixel Pitch | 0.315 mm |
| Response Time | 8 ms (Typ) |
| Refreshing Frequency | 60 Hz |
| Connectivity | |
| VGA/D-SUB | 1 x D-SUB |
| HDMI | 1 x HDMI OUT (4K), 3 x HDMI IN (HDMI 2.0) |
| USB | 1 x USB 2.0 4 x USB 3.0 (including 2 USB ports in front) |
| USB Type-C™ | 1 x USB Type-C™ |
| Audio in | 1 x 3.5 mm stereo phone jack |
| Audio output | 1 x Audio out |
| RS232 control | 1 x RS232 |
| Built-in speaker | Yes, 2 x 12 W |
| LAN IN | 1 x GIGABIT LAN (RJ45) |
| LAN OUT | 1 x GIGABIT LAN (RJ45) |
| TOUCH OUT | 2 x TOUCH OUT (USB 2.0) |
| SPDIF | 1 x SPDIF |
| WiFi | Yes, dual band, supports WiFi 6 |
| Touch System | |
| Sensing type | Infrared recognition |
| Touch point | 20 points touches, 10 points writing |
| Minimum object size | 3 mm |
| Writing height | ≤3 mm |
| Writing double colors with double pens simultaneously | Supports |
| Touch tool | Finger / Passive infrared pen / Active infrared pen |
| Response time | ≤10 ms |
| Accuracy | ±1.5 mm (over 90% area) |
| Communication mode | Full-speed USB (driver free) |
| Wireless Screen Mirroring | |
| Wireless Screen Mirroring | Supports |
| PIN code connection mode | Supports both static and dynamic pin codes |
| Maximum number of split screens / devices projecting to the Panel simultaneously (Panel standalone Android mode) | 9 |
| Self-hotspot Screen Mirroring | Supports |
| Native AirPlay protocol for Screen Mirroring | Supports |
| Native Chromecast protocol for Screen Mirroring | Supports |
| Native Miracast protocol for Screen Mirroring | Supports |
| Mirroring of Panel display to client devices | Supports |
| Reversely control Windows / MacOS during Screen Mirroring | Supports, client software required |
| Multi-Panels synchronization | Supports |
| Built-in moderator console | Yes |
| Power consumption (Typical) | |
| Soft switch off | ≤0.5 W |
| Overall power (max power) | 350 W |
| Electrical values | |
| Rated voltage range | 100 V – 240 V |
| Rated frequency range | 3.5 A |
| Quality and Reliability | |
| MTBF | 50,000 h |
| System | |
| CPU (Central Processing Unit) | Quad core A55 x 4 |
| GPU (Graphics Processing Unit) | Quad core Mali G52 |
| System memory | 4 GB |
| Storage | 32 GB |
| OS | Android 11 |
| Dimensions / Weight / Environmental | |
| Key location & number | Front physical keys, 1 |
| Dimension L x H x D | 1,271 x 774 x 87 mm |
| Dimension (package) L x W x H | 1,401 x 220 x 859 mm |
| Net weight | 26.1 kg |
| Gross weight | 34.45 kg |
| Thickness of machine and wall mount | 117 mm (9,060 G) |
| Wall-hanging screw spec | M8 x 25 mm |
| VESA | 400 x 200 mm |
